Tolerance Guide
Design tolerance references for faster engineering review.
What this guide covers
- Identify critical dimensions, fit surfaces and inspection datums before sending drawings.
- Separate standard tolerances from precision features that need engineering review.
- Add notes for measurement method, surface finish and assembly fit where they matter.
